Wireless Microphone Module

Wireless Microphone Module
Wireless Microphone Module
Get A Quote
Features
Technical Parameters

Features of Wireless Microphone Module GX-PA4012 / GX-PA4013 / GX-PA4014 / GX-PA4015 / GX-PA4016 / GX-PA4017 / GX-PA4018

  • Based on TCP/IP, UDP, IGMP protocol, support LAN and WAN transmission, can be installed anywhere the network can reach, to achieve access and control of servers and other network equipment

  • Through the Android or IOS sub-control software, you can control the on-demand and paging functions in real time

  • Built-in 4-channel switch encoding and decoding function

  • Built-in 4-channel audio decoding module, which supports the conversion of network audio signals into analog stereo signal output, and realizes the playback of background music, emergency paging, alarm signals, etc. from the server system

  • It has 1 stereo line input, supports local audio source playback, and the microphone volume is independently adjustable

  • With 2-channel mono line output, extended connection power amplifier output

  • With 2 sets of 100V constant voltage output, connected to constant voltage broadcast speakers, which can meet the requirements of different occasions

  • With 1 short circuit output, when there is a task, the short circuit triggers the work

  • With 1 emergency output, with 24V strong cut function

  • The 4-channel emergency output free switching function, when there is a task, the emergency output can be linked to other equipment

  • It has a 220V5A intelligent control power interface, which can be turned on and off automatically or manually. The system can be set to supply power regularly, which is intelligent and environmentally friendly

  • With output short-circuit protection, output limiting protection, overload protection, overheating protection and other protective measures to ensure the safe use of power amplifiers and speakers

  • With power indicator, signal indicator, peak clipping indicator, protection indicator

  • With indicator lights such as signal indication and network indication function, the status of the power amplifier is clear at a glance

  • It has the characteristics of high efficiency and energy saving, light weight, small size, high power, strong load capacity, etc

  • An offline storage module is optional, and it can also realize timing playback and timing ringing even when it is disconnected from the network

  • An optional USB Bluetooth module can be used to push audio to the terminal for playback via mobile phone Bluetooth

  • Optional USB 2.4G wireless microphone module to meet the needs of local microphone amplification output

  • Support remote server management and remote upgrade, which is convenient for users to maintain

Technical Parameters of Wireless Microphone Module GX-PA4012 / GX-PA4013 / GX-PA4014 / GX-PA4015 / GX-PA4016 / GX-PA4017 / GX-PA4018

ModelGX-PA4012/GX-PA4013/GX-PA4014/GX-PA4015/GX-PA4016/GX-PA4017/GX-PA4018
Output power4x60W/4×120W/4x240W/4×360W/4x500w/4x600W/4×800w
Constant voltage output100V±5%
Network interfaceRJ45*1, 100Mbps/10Mbps
Audio interfaceAUX_IN*1, MIC_IN*1, LINE_OUT*2
Memory interfaceUSB(U disk)*1, maximum support 128G
Other interfacesUSB (extension 2.4G wireless microphone)*1, short-circuit output*1, 24v strong cut power output*1, AC220V 5A OUT*1
Support protocolTCP/IP, UD, IGMP
Audio formatMp3
Audio mode16-bit stereo CD sound quality
Bit rate8k~768Kbps
AUXsensitivity0dB
MIC sensitivity-40dB
Frequency response20Hz~20KHz
Harmonic distortionTHD ≤1%(1/4 rated power)
Signal to noise ratio≥85dB
Short circuit output0V<5A
Protection circuitoverload, over temperature, short circuit protection
Power supplyAC220V±10%
Standby power consumption<3w
Product size485x410x90mm
Product weight11.2Kg/11.2Kg/11.2Kg/11.2Kg/11.5Kg/11.5Kg/11.5Kg
Working temperature-10~60 degrees
Environmental humidity20%~80% relative humidity
