Dual 12-inch Line Array Series Box Speaker

GX-SP2012DL-Z Box Speaker Line Array 12-inch

The GX-SP2012DL-Z Box Speaker Line Array 12-inch is a large-scale two-way crossover system providing a bandwidth of 55Hz-20KHz. Our 12-inch line array speakers are fitted with two British top-level 44 mm voice coil HF drivers coupled to a special constant-path aluminum horn and two 12-inch LF drivers with great dynamic margins. It produces strong penetrating power, clear and thick vocals and super high sound pressure levels. The whole speaker of 12-inch line array is beautiful and concise in shape, and exquisite in appearance, which is an extremely competitive large-scale line array system.


GX-SP2018DSBB-Z box line array 12-inch speaker

The GX-SP2018DSBB-Z box line array 12-inch speaker uses a custom-made speaker unit that is precisely modulated and the cabinet is a symmetrical compression design. It employs two 18" drivers in a symmetrically compressed enclosure, featuring extremely deep low frequency which has strong power and elasticity at the same time. Combined with GX-SP2012DL-Z, the box speaker line array 12-inch generates a large dynamic, high SPL, clear and delicate sound as well as a tunable full-range response range.

box speaker line array 12 inch
12 Inch Line Array Box Speaker
box speaker line array 12 inch
12 Inch Line Array Box Speaker
12 Inch Box Spekaer Line Array PDF 12-inch Box Speaker Line Array Price
Features
Technical Specifications

12 Inch Box Spekaer Line Array Features

1. A compact two-way passive, line array system, intended for use in arrays with fixed curvature.

2. This is a versatile loudspeaker system for medium & large indoor venues.

3. It is suitable in small and medium outdoor scale applications, or as a delay tower for large-scale sound reinforcement systems.

Box Speaker 12 Inch Line Array Technical Specifications


ModelGX-SP2012DL-ZGX-SP2018DSBB-Z
Impedance16Ω4Ω
Frequency range50Hz~20KHz(-10dB)35Hz~350Hz(-10dB)
MAX SPL137dB(EIAJ)139dB
Power(RMS)600W/ 2400W(PEAK)1200W/ 4800W(PEAK)
Horizontal coverage angle120°/
Vertical coverage angle10°/
MID-LF unit2*12 Mid Low,2*18"Subwoofer
3"High power voice coil4"High power voice coil
Ceramic alloy magnet,Ceramic alloy magnet
Waterproof paper coneWaterproof paper cone
HF unit2*1"Titanium film, Neodymium magnet, 1.75"tube/
Sensitivity(1m/1W)103dB/
Hanger/InstallationHanger for line array, two handles36mm stand holder, hanger for line array, two handles
Cabinet18mm birch plywood, black spray paint, metal mesh
Signal connectorTwo parallel socket of SPEAKON
Product Dimensions(W*D*H)1010*520*350mm1010*835*550mm
Net weight46.5Kg93Kg
Gross weight49Kg101.5Kg
